Construction, Maintenance and Repairs of Pipelines and Flow lines [Offshore and Onshore] Projects

ENGINEERING, PROCUREMENT, CONSTRUCTION AND INSTALLATION OF 40” AJAOKUTA – KADUNA – KANO (AKK) TRANS NIGERIAN GAS PIPELINE PROJECT – SECTION B.

Client: BRENTEXCPP/ NIGERIAN NATIONAL PETROLEUM CORPORATION
Status: ONGOING PROJECT
Scope of work

Specialized zones & encroachments crossing

Block valves installation

Pigging facilities

Metering stations

Terminal Gas stations

Cathodic protection

AC mitigation

FOC conduit

Markers and measuring post

Temporary site facilities

Temporary site utilities

Temporary access roads

Temporary security measures and installations
Category: EPCI

CONSTRUCTION OF A 30” & 26” SUBSEA BY-PASS PIPELINE AROUND THE ESCRAVOS -IMPORT BERTH PLATFORM.

Client: PIPELINES AND PRODUCTS MARKETING COMPANY
Status: ON-HOLD PROJECT
Scope of work

Carry out detailed under water survey to determine the most workable route for the by-pass.

Mobilisation and hire of a Multiservice work vessel suitable for

depths of 20-30 meters of water and associated support Equipment.

Procurement of 30” & 26” PE coated API X42, 13mm wall thickness Linepipes.

Procurement of 30” & 26” SMART FLANGE with connectors, 30” x 26” Reducer and all appurtenances.

Fabrication of a loop to link the two pipes segments.

Cutting of the 30” & 26” pipeline segments at the sea bed and connecting the subsea pipelines using the SMART FLANGES and connectors at the sea bed.

Provision and installation of concrete saddles designed to provide negative buoyance for the newly installed 30” pipeline segment.

Hydro testing the line from SBM to Escravos Terminal and commissioning of the installed segment.
Category: CONSTRUCT

PROVISION OF REPAIRS, MAINTENANCE AND SECURITY SERVICES ON WARRI TO KADUNA PPMC CRUDE AND PRODUCTS PIPELINE SEGMENTS.

Client: PIPELINES AND PRODUCTS MARKETING COMPANY / MRS OIL & GAS LIMITED
Status: COMPLETED PROJECT
Scope of work

Provision of detailed Work Execution Plan before commencement of all Repairs works, including discussion on the allocation of equipment needs.

Participate in a Joint Investigation Visit (JIV) by excavation of damaged pipeline section and lifting section so that it can be inspected by JIV prior to commencing the intended repair works.

Development of approved welding procedure.

Procurement of required Clamp/pipes, flanges and bolts for replacement of damaged section.

Repairs Works (Sectional Replacements, Parching, Clamping, Flanging).

Installation of New Cathodic System

Repair of TEG’s Station

Clean up of work site (including clean- up of spills and disposal).
Category: CONSTRUCT

LEAK REPAIR & REHABILITATION OF NEWCROSS 1O” EKULAMA II PIPELINE. LOCATION: EKULAMA, RIVER STATE

Client: NEW CROSS
Status: COMPLETED PROJECT
Scope of work
Provision of detailed Work Execution Plan before commencement of any construction works, including discussion on the allocation of equipment needs.
Exposure of existing 10“ damaged/leaked pipeline, and lifting of the overcrossing pipelines.

Participate in a Joint Investigation Visit (JIV) by excavation of damaged pipeline section and lifting section so that it can be inspected by JIV prior to commencing the intended repair works.

Development of approved welding/ Clamp procedure.

Procurement of required Clamp/pipes, flanges and bolts for replacement of damaged section.

Removal of damaged section of pipeline.

Installation and bolt-up of flanged repair spool section in position.

Service testing of pipeline system to verify integrity of bolted flange connections.

Recoating/taping of exposed/repaired areas, including bolted flange connections.

Lowering of line into trench and backfilling of access.

Clean up of work site (including clean-up of spills and disposal)
Category: CONSTRUCT

REPAIR OF BLAST POINTS AT INIKOROGHA AND AZAMA IN IBAFAN CREEKS AND HYDRO-TESTING OF THE 24" X 60KM ESCRAVOS - WARRI PIPELINE AND REPAIR OF POSSIBLE LEAK POINTS.

Client: PIPELINES AND PRODUCTS MARKETING COMPANY / OCEAN MARINE SOLUTIONS
Status: COMPLETED PROJECT
Scope of work

Mobilization of resources to leak repair location

Excavation of pipe trench for pipe lifting.

Exposure of the blasted portion of the pipeline.

Joint Inspection visit of Leak point for repair.

Lifting of 24” Pipeline section

Removal of coating.

Cutting off damaged areas of the 24” pipeline section using Cold cutter

Plugging of pipe end before hot work.

Cleaning and Preparation of 24” pipe end for fit up

Fit up and Welding of replacement pipe (upstream)

Fit up and Welding of replacement pipe (downstream)

Radiographic inspection of the welded joints.

Coating / Wrapping of Welded joints

Lowering of pipeline section into trench and Backfilling
Category: CONSTRUCT

CONSTRUCTION OF 20KM OF THE DUAL 10’ X 65KM AND 6” X 20KM PL FORM OWA-OLADINMA – OGHAREFE

Client: PAN OCEAN OIL CORPORATION
Status: COMPLETED PROJECT
Scope of work

ENGINEERING

CONSTRUCTION

PIPE HANDLING

TANSPORTATION OF LINEPIPES

COMMUNITY AFFAIRS MANAGEMENT

RIGHT OF WAY RECONNAISSANCE SURVEY/BUSH CLEARING

STRINGING LINE PIPES

WELD & LAY

PRECOMMISSIONING

INSTALLATION

LOWER-IN & BACK FILLING

CIVIL WORKS

COMMISSIONING & OPERATION OF THE FACILITIES

FABRICATION & INSTALLATION OF PIG LAUNCHER AT UPSTREM END

HOOKUP/TIE-IN AT THE CRUDE INTAKE FACILITIES
Category: CONSTRUCT

REPAIR OF ESCRAVOS FIREWATER TANK.LOCATION ESCRAVOS.

Client: CHEVRON
Status: COMPLETED PROJECT
Scope of work

Premobilization and Mobilization of Resources

Development of WPS

Procurement of Consumables

Sweep Blasting of Tank surface

Installation of Lighting and Extractor Fans

Fabrication of plates for Installation

Welding

NDT

Scaffolding Set-up

Blasting & Painting

Leak Testing

Cathodic Installation

Commissioning of Tank
Category: CONSTRUCT

REPAIR OF OLERO-ABITEYE 18” PIPELINE/SERVICE TEST AT BP21, BP24 & BP25.

Client: CHEVRON NIG. LTD
Status: COMPLETED PROJECT
Scope of work

EXPOSURE OF EXISTING DAMAGED PIPELINE SECTION

LIFTING OF THE PIPELINE

COLD CUTTING OF THE DAMAGED SECTION FROM PIPELINE

WELDING OF FLANGES ONTO PIPELINE ENDS

INSTALLATION OF PREFABRICATED HYDROTESTED FLANGED SPOOL CONSTRUCTION

PROVISION OF ENGINEERING LIFTING CALCULATIONS FOR COMPANY APPROVAL PRIOR TO LIFTING THE PIPELINE

COMMUNITY AFFAIR MANAGEMENT

WELD

FIELD JOINT COATING AND WRAPPING

LOWER-IN & BACK FILLING

COMMISSIONING
Category: CONSTRUCT

UMUSADEGE-KWALE 8” X 4.2KM PIPELINE CONSTRUCTION. INCLUSIVE OF NDT.

Client: PLATFORM PETROLEUM
Status: COMPLETED PROJECT
Scope of work

MOBILISATION OF RESOURCES TO SITE

PROJECT MANAGEMENT

PREPARATION OF FLOWLINE RIGHT OF WAY & ACCESS ROAD

STRINGING OF PIPELINE

WELDING OF PIPELINE

NON DESTRUCTIVE TESTS

CATHODIC PROTECTION

DITCHING & BACKFILLING

DEMOBILISATION OF RESOURCES FROM SITE

PROVISION OF AS-BUILT DOCUMENTS
Category: CONSTRUCTION

UMUTU-UMUSADEGE 6” X 11.5KM PIPELINE CONSTRUCTION, INCLUSIVE OF NDT.

Client: PLATFORM PETROLEUM
Status: COMPLETED PROJECT
Scope of work

ENGINEERING

CONSTRUCTION

PIPE HANDLING

RANSPORTATION OF LINEPIPES

COMMUNITY AFFAIRS MANAGEMENT

BUSH CLEARING

STRINGING LINEPIPES

WELD & LAY

FIELD JOINT COATING AND WRAPPING

INSTALLATION

PRECOMMISSIONING

LOWER –IN & BACK FILLING

CIVIL WORKS

COMMISSION AND OPERATION OF THE FACILITIES

FABRICATION AND INSTALLATION OF PIG LAUNCHER AT UPSTREAM END

HOOKUP/TIE IN
Category: CONSTRUCTION

OLERO RMP-9 FLOWLINES/STRUCTURAL REPAIRS, INCLUSIVE OF NDT.

Client: DEMACK/CHEVRON (SUBCONTRACT)
Status: COMPLETED PROJECT
Scope of work:
Category: CONSTRUCTION
